    Colorful Pre Painted Galvalume Coil / PPGI Steel Coil 0.20~1.50MM Thickness

    Ask Lasest Price
    Brand Name : Hanke
    Model Number : JIS G3322
    Certification : KS/GB/SGS
    Price : Negotiate
    Payment Terms : L/C, T/T, etc.
    Supply Ability : 300000 per year
    Delivery Time : 30-50 days
    • Product Details
    • Company Profile

    Colorful Pre Painted Galvalume Coil / PPGI Steel Coil 0.20~1.50MM Thickness

    Colorful Prepainted Galvalume Steel Coil 55% RAL PPGL PPGI AZ


    1. Category & Coding of Prepainted Steel Sheet


    ClassificationItemCode
    ApplicationsConstruction external useJW
    Construction internal useJN
    Steel windowsGC
    Household applianceJD
    FurnitureJJ
    OthersQT
    Surface FinishNormal coatedTC
    EmbossedYA
    PrintedYI
    Types of top coatingsPEPE
    Silicon moodified polyesterSMP
    High-durability polyesterHDP
    Polyvinylidene fluoridePVDF
    Base MetalElectro-galvanized base metalZE
    Hot-dip zinc coated base metalZ
    Hot-dip Al-Zn steel sheetAZ
    Coating surface structure of ot dip galvanized substrateSmall SpangleX
    Zero SpangleM
    Pretreatment types for substrate surfaceNormal chemical pretreatmentC
    Chrome free chemical pretreatmentC5
    Coating typeTop side two coats, bottom side one coatings2/1
    Top side two coatings, bottom side two coatings2/2
    Top side two coatings, bottom side two coatings2/1M

    2. Performance of coating film


    Common performance of top coating of Hanke's prepainted steel.


    CategoryThickness (μ)Pencil Hardness60° specular glossiness of coating180° bendImpact (J)Saltfog resistant (h)
    LowModerateHighThickness≤0.75mm
    A LevelB Level
    PE≥20≥F<4040~70>70≤5T≤3T≥9≥500
    SMP≥20≥F<4040~70>70≤5T≤3T≥9
    HDP≥20≥HB<4040~70-≤5T≤2T≥9≥1000
    PVDF≥20≥HB<4040~70-≤5T≤2T≥9≥1000

    3. Specification


    STANDARDJISG3312/ASTM A755M /GBT12754/EN10142
    THICKNESS0.20~1.50MM
    WIDTH1250MM MAX.
    ZINCZ180 MAX.
    PAINT15~20 MICRONS ON TOP SIDE, 5~7 MICRONS ON BACK SIDE
    PAINT LAYERPRIMER+PAINT/PRIMER OR PRIMER+PAINT
    PAINT TYPERMP, SMP, HDP, PVDF
    PAINT BRANDKCC, AKZO NOBEL,TWIN TIGERS, NIPPON
    PROTECTION FILMAVAILABLE
    PACKAGINGFACTORY STANDARD EXPORT PACKING
    COIL ID508MM OR 610MM
    COLORRED,BLUE,IVORY,GREY, RAL9002,RAL9003, ETC.
    COIL WEIGHT12MT MAX.

    4. Quality Assurance

    HANKE has already passed the authentification by the ISO9001, ISO14001 and KS D 3520 in succession and established a completed set of quality assurance system, and under this system, there has a complete set of regulations for ordering, order handling, quality design, purchasing raw materials, working production schedule, production, test, inspection, packaging, storage, delivering, etc.

    5. Our service:

    1) Free sample offered;
    2) Flexible payment term with L/C at sight,TT ,ect;
    3) Big quantity supply and short delivery time;
    4) Stable and reliable quality
    5) Long term after-sale service.
