    PVDF Galvanized Steel Roll 55% RAL 9002 9003 AZ Zinc Gloss Customized

    PVDF Prepainted Galvalume Steel Coil 55% RAL9002 9003 AZ Zinc


    1. The merits of polyvinylidene fluoride


    The finish coat of polyvinylidene fluoride features in its excellent retention of color, resistance of ultra-violet radiation, outdoors durability, chalking resistance, resistance to solvent, formability, good dirt resistance, finite colors and high cost.


    2. Performance of coating film


    Common performance of top coating of Hanke's prepainted steel.


    CategoryThickness (μ)Pencil Hardness60° specular glossiness of coating180° bendImpact (J)Saltfog resistant (h)
    LowModerateHighThickness≤0.75mm
    A LevelB Level
    PE≥20≥F<4040~70>70≤5T≤3T≥9≥500
    SMP≥20≥F<4040~70>70≤5T≤3T≥9
    HDP≥20≥HB<4040~70-≤5T≤2T≥9≥1000
    PVDF≥20≥HB<4040~70-≤5T≤2T≥9≥1000

    3. Specification


    STANDARDJISG3312/ASTM A755M /GBT12754/EN10142
    THICKNESS0.20~1.50MM
    WIDTH1250MM MAX.
    ZINCZ180 MAX.
    PAINT15~20 MICRONS ON TOP SIDE, 5~7 MICRONS ON BACK SIDE
    PAINT LAYERPRIMER+PAINT/PRIMER OR PRIMER+PAINT
    PAINT TYPERMP, SMP, HDP, PVDF
    PAINT BRANDKCC, AKZO NOBEL,TWIN TIGERS, NIPPON
    PROTECTION FILMAVAILABLE
    PACKAGINGFACTORY STANDARD EXPORT PACKING
    COIL ID508MM OR 610MM
    COLORRED,BLUE,IVORY,GREY, RAL9002,RAL9003, ETC.
    COIL WEIGHT12MT MAX.

    4. Advantages of PPGI:


    a. resistance to acid rain

    b. resistance to ultraviolet rays

    c. resistance to humid heat

    d. resistance to low temperature

    e. intense heat reflectance.

    f. intense skin-pass surface


    5. Quality Assurance

    HANKE has already passed the authentification by the ISO9001, ISO14001 and KS D 3520 in succession and established a completed set of quality assurance system, and under this system, there has a complete set of regulations for ordering, order handling, quality design, purchasing raw materials, working production schedule, production, test, inspection, packaging, storage, delivering, etc.

    6. Our service:

    1) Free sample offered;
    2) Flexible payment term with L/C at sight,TT ,ect;
    3) Big quantity supply and short delivery time;
    4) Stable and reliable quality
    5) Long term after-sale service.
