Construction Galvanized Steel Coil Regular Spangle 1.5mm Thickness / 1200mm Width

Wuhan Hanke Color Metal Sheet Co., Ltd.
Contact Now
    Buy cheap Construction Galvanized Steel Coil Regular Spangle 1.5mm Thickness / 1200mm Width from wholesalers

    Buy cheap Construction Galvanized Steel Coil Regular Spangle 1.5mm Thickness / 1200mm Width from wholesalers
    • Buy cheap Construction Galvanized Steel Coil Regular Spangle 1.5mm Thickness / 1200mm Width from wholesalers

    Construction Galvanized Steel Coil Regular Spangle 1.5mm Thickness / 1200mm Width

    Ask Lasest Price
    Brand Name : HANKE / WISCO
    Model Number : DX51D+Z,, SGCC, ASTM A653M
    Certification : KR , ISO9001
    Price : Negotiate
    Payment Terms : L/C, T/T
    Supply Ability : 300000 per year
    Delivery Time : 30-50 days
    • Product Details
    • Company Profile

    Construction Galvanized Steel Coil Regular Spangle 1.5mm Thickness / 1200mm Width

    Construction Regular Spangle Galvanized Steel Coil 1.5mm Thickness and 1200mm Width


    1. Introduction


    Galvanized steel coils are produced through a preocess of metal coating which involves passing cold rolled coils through a kettle containing molten zinc. This process ensures adhesion of zinc to the surface of the steel sheet. The zinc layer provides excellent corrosion resistance and prolong service life.

    Hot dipped galvanized products are widely used in household appliances, transport, container manufacturing, roofing, base material for pre-painting, ducting and other construction related applications.


    2. Specification


    NameGalvanized Steel Coil
    GradeDX51D+Z, DX52D+Z, SGCC, SGCH, ASTM A653M, ASTM A792M
    StandardGBT2518-2008, JIS G3302, ASTM A653M, EN10327
    CertificateKR, ISO
    Thickness0.2mm-2.0mm
    Width600mm-1250mm
    Coil Id508mm, 610mm
    Zinc Coating40g-180g/M2
    SurfaceChromated, Oiled / Unoiled, Dry, Skin-Passed
    SpangleRegular Spangle
    Coil Weight3-15mt or as customer’s request
    PackingStandard Export Packing
    ApplicationArchitecture,Electrical Home Appliances, Traffic, etc.
    Payment TermBY T/T or L/C
    ShipmentBY container or bulk

    3. Width tolerance


    Width tolerance of the hot-dip zinc steel sheets could conform to relecant parameters as below:

    Nominal WidthWidth tolerance
    Common precise PW.AHigh-level precision PW.B
    ≤1200mm0~+50~+2
    >1200mm~1500mm0~+60~+2
    >1500mm0~+70~+3

    4. The process of hot-dipped galvanized steel


    Uncoiler-->Welder-->Entry Looper-->Pre-treatment-->Anneling furnace-->Zinc pot-->Cooling tower--> Water quench tank-->Skin pass-->Tension leveler-->Passivation coater-->Exit Looper-->Recoiler

    5. Applications


    1) Infrastructure: Building & Construction: Roofing; Terrace; Window Frame; Door: Rolling-up Door; Shutter; Mobile House;Interior Decorations: Wall; Door Frame; Steel Structure; Screen; Ceiling; Elevator;

    2) Transportation :Auto Panel; Interior Decorative Panel; Carriage Panel


    6. Our service:


    1) Free sample offered;

    2) Flexible payment term with L/C at sight,TT ,ect;

    3) Big quantity supply and short delivery time;

    4) Stable and reliable quality

    5) Long term after-sale service.
