    Hanke Aluzinc PPGL Steel Coil SGLCC SGLCD DX51D 52D 53D ISO 9001 Approved

    Aluzinc PPGL Steel Coil SGLCC SGLCD DX51D 52D 53D GB Standard KS


    1. Definition


    The basic material for Colorful Steel Coils is hot galvanized steel sheet or high strength aluminum alloy sheet. Using the most state of art technique and equipment to degrease the cold rolled sheet, hot galvanized steel sheet or high strength aluminum alloy sheet on multistage, and rinse, chemical transformation treatment, then continuously clean the steel strip and aluminum strip. Moreover, use the most advanced curing furnace to solidify/baking the coating.


    2. Specification


    NamePPGL
    Thickness0.14mm-2.0mm
    Width≤ 1250mm
    LengthAs per customer's requirement
    Zinc Coating30-275g/m2
    Type of Coating Structure2/1 or 2/2 coating or customized
    Painting thickness15-30/5-20UM
    ToleranceWidth: +/-5mm
    thickness: +/-0.005mm
    ColorRAL color or according the sample
    Weight of each packageabout 3-5mt
    Coil ID508 / 610mm
    Surface TreatmentGalvanized, chromated, bright finished, unoiled(oiled) and fingerprint-resistant
    MaterialSGCC, CGCC, DX51D, DX52D, DX53D
    StandardASTM, JIS, DIN, GB
    Packingexport seaworthy package or as customer's requirement

    3. Category & Coding of Prepainted Steel Sheet


    ClassificationItemCode
    ApplicationsConstruction external useJW
    Construction internal useJN
    Steel windowsGC
    Household applianceJD
    FurnitureJJ
    OthersQT
    Surface FinishNormal coatedTC
    EmbossedYA
    PrintedYI
    Types of top coatingsPEPE
    Silicon moodified polyesterSMP
    High-durability polyesterHDP
    Polyvinylidene fluoridePVDF
    Base MetalElectro-galvanized base metalZE
    Hot-dip zinc coated base metalZ
    Hot-dip Al-Zn steel sheetAZ
    Coating surface structure of ot dip galvanized substrateSmall SpangleX
    Zero SpangleM
    Pretreatment types for substrate surfaceNormal chemical pretreatmentC
    Chrome free chemical pretreatmentC5
    Coating typeTop side two coats, bottom side one coatings2/1
    Top side two coatings, bottom side two coatings2/2
    Top side two coatings, bottom side two coatings2/1M

    4. Production core strengths


    1) Resistance to acid rain: Coating protection mechanism: It is very easy to form acid rain in the high level of industrial emissions or pollutants environment. Acidic penetration is formed in the surface of pre-painted steel, and accelerates the corrosion, forming blistering, peeling and so on.
    2) Resistance ultraviolet rays: Coating protecting Mechanism: pre-painted sheet in ultraviolet or strong sunlight conditions, the coating will exhibit chalking degeneration, manifested as discoloration and loss of gloss, lose paint quickly.
    3) Resistance to humid heat: Coating protecting mechanism: in hot and humid environments, high osmotic pressure of water vapor accelerates penetration, forming the degeneration of painting film, then the corrosion of the substrate, with the phenomenon of bubbles and peeling.
    4) Resistance to low temperature: Coating protecting mechanisms: most of the paint can keep stable processing performance above -10 degree, but at alpine region, the temperature will be below 20-40 degree, normal paint will become brittle,bend cracking, or even lose paint, thus protection function is lost totally.

    5. Quality Assurance


    HANKE has already passed the authentification by the ISO9001, ISO14001 and KS D 3520 in succession and established a completed set of quality assurance system, and under this system, there has a complete set of regulations for ordering, order handling, quality design, purchasing raw materials, working production schedule, production, test, inspection, packaging, storage, delivering, etc.
